46.2 Gallons/Minute

1" Fluid Port

Technical Data

• Air Inlet : 3/8" Female NPT (includes ball valve)
• Air Exhaust : 3/4" Female NPT (includes silencer)
• Air Supply Pressure : 20 to 100 PSI (1.4 to 7 kgf/cm²)
• Discharge Volume Per Cycle : Rubber diaphragm: 0.163 gallons (615 cc) PTFE diaphragm: 0.143 gallons (539 cc)
• Maximum Cycles Per Minute : Rubber diaphragm: 195 PTFE diaphragm: 195
• Maximum Size Solid : 3/16" (4.8 mm) (NDP)
• Maximum Dry Suction Lift : Rubber-fitted pump capability: 18-feet
• Air Motor : Aluminum
• Optional Coating : PTFE-coated (NDP)

Dimension

• Dimensions: 11.27" W x 14.74" H
• Net Weight: 44.1 lbs. (20 kg)
• Shipping Weight: 49.1 lbs.
