3.4 Gallons/Minute Max.

1/4" NPT Fluid Port

Technical Data

• Intake & Discharge Connection : 1/4" Female NPT
• Air Inlet : 1/4" Female NPT (includes ball valve)
• Air Exhaust 3/8" Female NPT (includes silencer)
• Air Supply Pressure : 20 to 100 PSI (1.4 to 7 kgf/cm2)
• Discharge Volume Per Cycle : 0.0085 gallons (35 cc)
• Maximum Cycles Per Minute : 400
• Maximum Dry Suction Lift : 5-feet
• Air Motor : Standard Ryton® Air Motor
• Muffler : Internal

Dimension

• Dimensions: 6.10" W x 5.87" H
• Net Weight: 3.5 lbs. (1.6 kg)
• Shipping Weight: 5 lbs.
• Max Liquid Temperature : 212F (100C)
